EdgeCut processes edge material made from ABS, PVC, PP, paper, thermoplastic foils, laminates or fleece backed veneer up to a thickness of 2 mm.
This system does not only minimise the potential hazard to the operator, but also shortens setup times dramatically.
- Edge material
Would you like to receive a free consultation to find out if EdgeCut is the solution you need?
Contact us for a non-binding, first conversation.
The cutting system developed by Duespohl makes it possible to cut and wind absolutely free of burrs and crease-whitening. The result is the highest quality in cutting thin papers, thermoplastic films and up to 2 mm thick edge materials, such as ABS or PVC. One of the biggest challenges was the fully automatic knife positioning as Duespohl’s well-known AutoCut performs it. The user specifies the desired cutting widths individually via touchscreen or retrieves them from a database. The adjustment process is completed in less than two minutes and guarantees a cutting width tolerance of no more than +/- 0.1 mm.
- Material thickness: up to 2 mm, depending on material qualities
- Working width up to 700 m
- Strip width min.: 18 mm
- Roll diameter max.: 700 mm
- Cutting speed: 10-150 m/min
The optional equipment includes:
Automatic knife positioning
Auxiliary to position cardboard cores easily and speed up set-up times
Rewinding with friction winding shaft for equal rewinding results of all reels
Reels will be rewound with edges aligned
High drive power for ultra-tight winding results
Constant tension during unwinding and rewinding for constant rewinding results
Sensitive rewinding for sandwich foils with acrylic layers
